Single-Parameter Analyzers
ORP Online Analyzer YG-ORP/P7
Las especificaciones detalladas se muestran en inglés.
The ORP online analyzer is an intelligent online water quality analyzer. It uses imported components, advanced production processes and measurement-and-control technology to keep the instrument stable, reliable and accurate over long-term operation.
Typical applications
- Water Treatment Plants
- Water Distribution Network
- Swimming Pools
- Cooling Circulating Water
- Aqueous solutions in water treatment projects and similar
yan@yuangankeji.com · +86-400-1688-667 · WhatsApp +86 151 7883 0466
Overview
The ORP online analyzer is an intelligent online water quality analyzer. It uses imported components, advanced production processes and measurement-and-control technology to keep the instrument stable, reliable and accurate over long-term operation.
The ORP online analyzer has a large color touchscreen interface and supports remote monitoring through the cloud platform and mobile devices. The transmitter outputs ORP and temperature over RS485. It is used for continuous monitoring and control of ORP in water treatment plants, distribution networks, swimming pools, cooling circulating water, water treatment projects and other aqueous solutions.
Key features
- 01
Simultaneous output
ORP value, temperature, etc.
- 02
4–20 mA output
Analog output (optional)
- 03
Better data presentation
7-inch color touchscreen
- 04
Remote data access supported
Built-in 4G module
- 05
View data anytime, anywhere
Works with the Water Quality Cloud platform
Technical Specifications
| Operating voltage: | 100–240VAC, 50/60 Hz |
|---|---|
| Power: | 10 W (peak power) |
| Operating mode: | Flow-through |
| Sample flow velocity: | Not less than 400 mL/min |
| Range: | ORP: -2000 mV~+2000 mV Temperature: -5–60 °C |
| Resolution: | ORP: 1 mV Temperature: 0.1 °C |
| Accuracy: | ORP: ±20 mV Temperature: ±0.4 °C |
| Measurement method: | ORP: electrochemical (electrode) method Temperature: thermistor method |
| Operating temperature: | -5–45 °C |
| Dimensions: | 300 × 450 × 170 mm (W × H × D) |
| Housing material: | ABS |
| Digital output: | RS485 Modbus protocol (4–20 mA optional) |
| (Note: specifications may change with product improvements; YuanGan reserves the right to modify them.) | |
Request a quote for YG-ORP/P7
Tell us your application, parameters and volume. Our export team replies by email or WhatsApp.
